The Excelta 7204E angled cutter has a Very Large Angulated Head and Molded Grip with Maximum cutting edges. Cuts up to 21 AWG soft wire.
Induction hardened cutting blades to RHC 63-65. The set-screw located in the jaws prevent the blades from over-travel and also prolong the life of the cutting blades. The CNC machining allows the joint surfaces to be perfect to allow for long life. The grips are molded and are static dissipative (10⁸ ohms/sq). The dual leaf springs provide smooth action.
7204E Cutter Specifications
|Tip Size:||.04" (1mm) x .24" (6mm)|
|Type of Cut:||Maximum Flush|
|Cutting Capacity:||.003"-.025" soft (.08mm - .63mm soft)|
|Over All Length:||5" (125mm)|
|Body Width:||.42" (10.5mm)|
|Body Height:||.275" (6.88mm)|
