Metcal HCT2-200 Digital Hot Air System 110V or 240V

Metcal HCT2-200 Digital Hot Air System 110V or 240V

MET-HCT2-200-11

$789.00
$789.00
Sale Sold out
Shipping calculated at checkout.
Choose Input Voltage

Metcal HCT2-200 Digital Hot Air System, Precision Rework for Miniature Components

The Metcal HCT2-200 is a compact, digital hot air pencil system designed for high-precision rework of miniature surface mount components. Ideal for low-density PCBs, this tool offers unmatched control and ergonomic performance for delicate rework applications.

Key Features

  • 200W ceramic heater with fast thermal response
  • Digital controls with dual LED temperature and airflow display
  • Lightweight, pencil-style ergonomic handpiece for detailed work
  • Six interchangeable precision nozzles (1.5 mm – 4.0 mm) included
  • Standby mode for extended heater life
  • Microprocessor-controlled closed-loop feedback system
  • Tool-free nozzle, heater, and handpiece replacement

Description

The Metcal HCT2-200 Digital Hot Air System is engineered for precision electronics rework, particularly in environments where **miniature components like 01005s and 1206s** are used. Unlike larger hot air rework systems that risk disturbing adjacent parts, the slim, ergonomic pencil design of the HCT2-200 allows for precise targeting without collateral airflow damage.

Featuring a 200-watt ceramic heater, dual-stage air pump, and real-time digital control over airflow and temperature, the HCT2-200 delivers consistent performance across a wide thermal range (100°C–450°C). A closed-loop feedback system ensures quick heat-up times and stability for sensitive SMD rework.

Designed for use under a microscope, the HCT2-200 also supports optional bent nozzles for greater visibility and control. This makes it an essential tool for R&D labs, repair centers, and electronics manufacturers focused on high-precision assemblies.

Technical Specifications

Specification Detail
Input Voltage 110 VAC, 60 Hz
Rated Power 200 W
Temperature Range 100 - 450 °C (212 - 842 °F)
Heating Method Convection
Airflow 1.5 - 7 l/min
Noise Level < 52 dBA at max airflow
Surface Resistivity 105 - 109 Ohm
Display Dual LED for temperature and airflow
Dimensions (W x D x H) 10.6 x 21.3 x 17 cm (4.2" x 8.4" x 6.7")
Weight 2.63 kg (5.8 lb)
Certifications CNRTLus, CE, RoHS, WEEE, cTUVus
Operating Temperature 10 - 40 °C (50 - 104 °F)
Power Cord Length 183 cm (18/3 SJT)
Warranty 1 Year

What’s Included

  • Base Unit
  • Ergonomic Handpiece
  • Workstand with Nozzle Holder
  • Heater Assembly
  • Six Precision Straight Nozzles (1.5 mm – 4.0 mm)
  • Nozzle Removal Pad

Recommended Use Cases

  • Reworking very small SMD packages (e.g. 01005, 0402, 1206)
  • Low-density PCB assemblies
  • Microscope-assisted rework
  • Prototype and repair labs

Note: For high-density PCBs, heavy copper planes, or components > 5mm, use with a Metcal PCT-100 series preheater is recommended.

Why Buy the Metcal HCT2-200?

When rework precision matters, the HCT2-200 delivers. Designed specifically for today's miniature components and tight layouts, it offers clean, controlled reflow with less risk to nearby parts. With its user-friendly interface, modular design, and included accessories, this is the professional’s choice for detailed SMD repair.

Equip your bench with the Metcal HCT2-200 and gain control, precision, and confidence in every rework job.
